ULTRA
Medusa Ultra is the next evolution of flexible linear lighting, expanding the capabilities of Medusa series with seamless, homogeneous illumination over continuous lengths up to 50 meters (164 ft).
Designed for demanding architectural applications, Medusa Ultra combines reinforced flexibility, effortless on-site customization, and robust IP67/IP68 protection with a refined matte finish — bringing technical precision and architectural elegance together for indoor and outdoor environments.
Features
Key Features
Seamless Long-Run Illumination
Medusa Ultra delivers smooth, homogeneous lighting across continuous runs up to 50 meters. Constant-current technology ensures uniform output and dot-free appearance, making it ideal for large-scale architectural applications.
Reinforced Flexibility & Easy Customization
A strengthened internal structure provides high bend and pull resistance while maintaining flexibility. Full accessory support enables fast on-site customization and seamless adaptation to complex design requirements.
Engineered for Performance & Longevity
Multi-layer FPC construction minimizes voltage drop while improving conductivity and heat management. This advanced design enhances stability and supports reliable performance over extended operating hours.
Durable Protection with Refined Finish
Food-grade silicone and a dust-proof matte coating combine durability with a premium appearance. With IP67/IP68 protection and IK08 impact resistance, Medusa Ultra performs reliably indoors and outdoors.
Gallery
Configurations
Bending Options
Bending
Side-Bend
Bending
Top-Bend
Configurations
Power Cable Feed
Power Feed
Rear Feed
Power Feed
Side Feed
Power Feed
Bottom Feed
Accessories
Mounting & Fixation
Bracket & Screw
(316 Stainless Steel)
Aluminum Profile
Bendable Profile
(316 Stainless Steel)
Specifications
Technical Data
CCT - Color Temperature
2700K, 3000K, 3500K, 4000K, 5000K, 6000K
CRI - Color Rendering Index
>80CRI, >90CRI
Luminous Flux Density
Top-Bend - 250lm/ft @ 64ft run length
Side-Bend - 170lm/ft @ 64ft run length- Lumen output drops by 50% when 164ft is reached -
Top-Bend - 250lm/ft @ 64ft run length
Beam Angle
120°
120°
Overal Dimension
- Field Cuttable at 50mm (1.97in) increments -
Finish
Milky White
Installation
Multiple options - Refer to Accessories
Operating Voltage
24VDC
Dimming & Controls
0–10 V / 1–10 V / DALI / PWM / CASAMBI
0–10 V / 1–10 V / DALI / PWM / CASAMBI
Power
Top-Bend - 4.27W/ft (14W/M)
Side-Bend - 4.27W/ft (14W/M)
Top-Bend - 4.27W/ft (14W/M)
Light Engine
Using FPC Technology for durability and robustness
Using FPC Technology for durability and robustness
